公司街连廊
无接缝双曲面上的对角网格
![](https://freight.cargo.site/t/original/i/becc3c711b2c6a3aeb66a2993493f795c2fe17992d6e2bb46f626f7e1b1c7eda/howtorhino_95618576_156974919187893_5306321661888896111_n.jpg)
![](https://freight.cargo.site/t/original/i/d44881e76442b48e16a6513b468eadf5b310605c5a7678a03cdefd37a9e78823/howtorhino_95470043_2951705131591223_528204053289287540_n.jpg)
![](https://freight.cargo.site/t/original/i/69b5299bb06c92149f27cfda563759260df918154522c7af0fbb3a90c990cfab/howtorhino_95321881_580564619332149_6509528290009552167_n.jpg)
![](https://freight.cargo.site/t/original/i/5bfa1e1727a767bebeda2d6a4ada710cc1793e4c1c1d3f1e7efd351dcdb1afe9/howtorhino_95283434_110103513861970_2015763372106753560_n.jpg)
![](https://freight.cargo.site/t/original/i/39f17a0ce465322c5d0f60dc9061b27f1d7ac782cb4ba97c223d5dba6c378df5/-682x.png)
(机翻中文字幕,待替换)
标签: Grasshopper,连廊
![](https://freight.cargo.site/t/original/i/a30962943b4e2d0d525222dc1b79947fffd72d5f0041127c3243329f7d26ca08/3.jpg)
![](https://freight.cargo.site/t/original/i/fa943c80b254774f37a603e5ba7f1ff399a161dc1999e765fff4ac83c860ba15/1.jpg)
在这个综合教程中,妳将学习如何在没有接缝线的周期性表面(闭合 Brep)上创建对角网格。我们将涵盖定义中的三个部分。第一个将是基本双曲面形状的创建和玻璃面板的划分。第二部分包括创建结构管道,第三部分是连接天桥与周围建筑物的连接件。
项目信息: 公司街大桥
由 Hodder + Partners 设计
地点:英国曼彻斯特
成为他们的 Patreon 支持者,获得所有案例文件,还有专属的进阶教程。
